MLM15 Multifunction Sound Stage Monitor

Logic Systems Pro Audio

400W 15" Mid Bass cone with 3" HF

The MLM Series is a range of state of the art live sound stage monitors. The MLM15 cabinet combines a 15” Mid/Bass cone with a coaxially mounted 3” HF voice coil, which is passively crossed over. The coaxial layout has many acoustic advantages and also means that with a centrally mounted HF driver matched pairs are not required. To aid functionality the cabinet also benefits from a tophat mount which enables the cabinet to be used for small front of house applications.

The monitor also benefits from being low profile to improve those all important sight lines. Another useful feature is link through speakons on the cabinet ends, ensuring neat cabling when used as pairs.

Technical Information:

Technical Specification
Frequency Response 50Hz – 18kHz
Components Bass/mid: 15” cone driver
HF: 3” voice coil, coaxially mounted
Power Handling 400w
Sensitivity 97dB
Directivity 60° conical above 1kHz
Impedance 8 Ohms nominal
Construction 15mm & 24mm Birch plywood
Finish Water based textured black paint
Connections 2 x Neutrik NL4 connectors
1+/1- Input 2+/2- no connection
Dimensions 565mm (W) x 360mm (H) x 495mm (D)
Packaged Dimensions 710mm (W) x 490mm (H) x 625mm (D)
Weight 27Kg

Cabinet Information:

Cabinet MLM15
Handles Yes
Tophat Yes
M20 No
Castors No
Bracket Pt. Yes
Inserts / Fly
