N8 Notion Sound 200W Portable Loudspeaker

Logic Systems Pro Audio

200W Portable Loudspeaker

The Notion 8 is a compact, high power, fullrange loudspeaker enclosure. The cabinet combines an 8” neodymium mid/bass cone with a 1” neodymium compression driver on a 70° x 50° horn flare. The horn flare rotates to aid use in both landscape and portrait applications. The cabinet can be used Fullrange or combined with the NB12 bass enclosure to form an integrated system. The Notion 8 contains an internal passive crossover network.

The multipurpose nature of the cabinet makes it suitable for a variety of applications including, FOH, stage fills and delays. Target markets for the product include church, live sound, theatre, installation and A/V.

Technical Information:

Technical Specification
Frequency Response 65Hz – 20kHz
Components Bass/mid: 8” Neodymium cone driver
HF: 1” exit Neodymium compression driver
Power Handling 200w
Sensitivity 95dB
Directivity 70° x 50° above 2kHz
Impedance 8 Ohm
Construction 15mm Birch plywood
Finish Water based textured black paint
Connections 2 x Neutrik NL4 connectors
1+/1- Input 2+/2- N/C
Dimensions 250mm (W) x 425mm (H) x 290mm (D)
Packaged Dimensions 380mm (W) x 580mm (H) x 770mm (D)
Weight 11 KG

Cabinet Information:

CABINET SPEC
Cabinet Notion 8
Handles 1 off
Tophat Yes
M20 No
Castors No
Bracket Pt. Top/Side/Rear
Inserts / Fly
Points:
9 off
