N10 Notion Sound 400W Portable Loudspeaker
Logic Systems Pro Audio
400W Portable Loudspeaker
The Notion 10 is a compact, high power, fullrange loudspeaker enclosure. The cabinet combines a 10” neodymium mid/bass cone with a 1” neodymium compression driver on a 90° x 75° horn flare. The horn flare rotates to aid use in both landscape and portrait applications. The cabinet can be used Fullrange or combined with the NB12 or NB15 bass enclosures to form an integrated system. The Notion 10 contains an internal passive crossover network.
The multipurpose nature of the cabinet makes it suitable for a variety of applications including FOH, stage fills and delays. Target markets for the product include church, live sound, theatre, installation and A/V.
Technical Information:
| Technical | Specification |
|---|---|
| Frequency Response | 55Hz – 20kHz |
| Components | Bass/mid: 10” Neodymium cone driver HF: 1” exit Neodymium compression driver |
| Power Handling | 400w |
| Sensitivity | 96dB |
| Directivity | 90° x 75° above 1.5kHz |
| Impedance | 8 Ohm |
| Construction | 15mm Birch plywood |
| Finish | Water based textured black paint |
| Connections | 2 x Neutrik NL4 connectors 1+/1- Input 2+/2- N/C |
| Dimensions | 305mm (W) x 520mm (H) x 360mm (D) |
| Packaged Dimensions | 840mm (W) x 680mm (H) x 420mm (D) |
| Weight | 16 KG |
Cabinet Information:
| CABINET | SPEC |
|---|---|
| Cabinet | Notion 10 |
| Handles | 2 off |
| Tophat | Yes |
| M20 | No |
| Castors | No |
| Bracket Pt. | Top/Side/Rear |
| Inserts / Fly Points: |
10 off |
